Hibot SQUID

By Hibot

SQUID is a complete robotic inspection system for water tubes in industrial boilers.

SQUID is a complete robotic inspection system for water tubes in industrial boilers. HiBot describes three cooperating modules: a sensor robot, a reel for deployment and retrieval, and a pump supporting movement through water flow. Ultrasonic channels measure around the tube wall and produce wall-thickness maps. HiBox supports data alignment and reporting. The system is not a standalone sensor. The manufacturer lists field-confirmed tube diameters and access conditions for the installation. An inspection project should therefore first check tube geometry, access, water conditions and power supply. The listed value describes inspection distance inside the installation, rather than travel across a site.

Status 2026

Commercially availableThis model is listed as commercially available. Delivery, configuration and support vary by supplier and region.
Type
Inspection and security robots
Origin
Japan
Deployment
Not confirmed
Region
Not publicly confirmed
Applications
2 applications
    Hibot SQUID
    Inspection speed
    Up to 100 mm/s
    Measurement channels
    24 ultrasonic channels
    Tube internal diameter
    50–68.2 mm internal diameter, field-confirmed water tubes
    Inspection distance
    Up to 40 m inspection distance

    Requires header and water tubes filled with pure water; 100/240 V AC supply. Tube diameters are field-confirmed; other sizes require manufacturer assessment. Reach is inspection distance.

    What is Hibot SQUID?

    Hibot SQUID is an inspection and security robot from Hibot from Japan, listed for wall-thickness measurement in industrial boiler tubes and reporting ultrasonic tube inspections. Key figures: inspection speed Up to 100 mm/s, measurement channels 24 ultrasonic channels, tube internal diameter 50–68.2 mm internal diameter, field-confirmed water tubes, inspection distance Up to 40 m inspection distance. Market status: commercially available. Availability and deployment options should be confirmed with a supplier. Robotleasen does not sell robots; it helps businesses compare suppliers and recorded information.

    Application

    What was SQUID developed for?

    • Wall-thickness measurement in industrial boiler tubes

    • Reporting ultrasonic tube inspections

    Business fit

    When might SQUID be a fit?

    An initial view based on the recorded category and model information

    What Hibot says

    • SQUID is a complete robotic inspection system for water tubes in industrial boilers.
    Source: Hibot — product documentation

    May be suitable for

    • Organisations assessing a robot for a defined task and work environment.
    • Teams comparing the robot's recorded profile with other options.
    • Businesses that want to validate the application and integration requirements.

    Considerations

    • Confirm capabilities and current availability with the manufacturer or supplier.
    • Check the work environment, integration needs and local support before selecting a model.

    Video

    SQUID in action

    Video from the manufacturer or an authorised partner.

    Source: hibot Corporation
    View video at source

    YouTube termsGoogle privacy

    Market and supply

    Is SQUID available?

    A profile status is not a confirmed offer or delivery time

    What is settled?

    Checked 3 October 2026
    • Market status
      Commercially available

      The model is on sale; you can request it from a supplier.

      confirmed
    • Region
      Not publicly confirmed

      Not known whether it is supplied in the Netherlands. Ask a supplier.

      not confirmed
    • Lease / RaaS
      Not confirmed

      No supplier has confirmed lease or robot-as-a-service.

      not confirmed
    • Rental
      Not confirmed

      No supplier has confirmed rental.

      not confirmed

    1 of 4 settled. The rest depends on the supplier.

    Ask about availability

    Manufacturer

    Hibot

    Modular inspection arm for pipes, tanks and hard-to-reach industrial structures.

    Not publicly confirmed2 robot profiles in the directory
    View

    OUR INTERPRETATION

    Our perspective on SQUID

    SQUID is a complete robotic inspection system for water tubes in industrial boilers. HiBot describes three cooperating modules: a sensor robot, a reel for deployment and retrieval, and a pump supporting movement through water flow. Ultrasonic channels measure around the tube wall and produce wall-thickness maps. HiBox supports data alignment and reporting. The system is not a standalone sensor. The manufacturer lists field-confirmed tube diameters and access conditions for the installation. An inspection project should therefore first check tube geometry, access, water conditions and power supply. The listed value describes inspection distance inside the installation, rather than travel across a site.

    Lease or rent

    Can you lease this robot?

    Leasing options for this model are not in our data. Ask the supplier about leasing, rental or Robot-as-a-Service, or use our request page for advice.

    Request advice

    Compare

    Compare SQUID with alternatives

    Open comparison overview
    FeatureSQUIDHibot · this robotIguanaExailCameleon LGExailDragonfish SeriesAutel Robotics
    Market statusCommercially availableCommercially availableCommercially availableCommercially available
    ApplicationWall-thickness measurement in industrial boiler tubes, Reporting ultrasonic tube inspectionsReconnoitring difficult-to-reach locations with cameras, Moving sensor equipment during professional inspectionsReconnoitring locations remotely with cameras, Supporting inspections with interchangeable sensor equipmentEnergy-infrastructure inspection, Observation for monitoring and emergency management
    DeploymentNot confirmedNot confirmedNot confirmedNot confirmed
    RegionNot publicly confirmedNot publicly confirmedNot publicly confirmedNot publicly confirmed
    Difference—Different application: reconnoitring difficult-to-reach locations with camerasDifferent application: reconnoitring locations remotely with camerasDifferent application: energy-infrastructure inspection

    Frequently asked questions

    Questions about SQUID

    What is the Hibot SQUID?

    Hibot SQUID is an inspection and security robot from Hibot from Japan, listed for wall-thickness measurement in industrial boiler tubes and reporting ultrasonic tube inspections. Key figures: inspection speed Up to 100 mm/s, measurement channels 24 ultrasonic channels, tube internal diameter 50–68.2 mm internal diameter, field-confirmed water tubes, inspection distance Up to 40 m inspection distance. Market status: commercially available. Availability and deployment options should be confirmed with a supplier. Robotleasen does not sell robots; it helps businesses compare suppliers and recorded information.

    What are the specifications of the Hibot SQUID?

    Key figures: inspection speed Up to 100 mm/s, measurement channels 24 ultrasonic channels, tube internal diameter 50–68.2 mm internal diameter, field-confirmed water tubes, inspection distance Up to 40 m inspection distance. Requires header and water tubes filled with pure water; 100/240 V AC supply. Tube diameters are field-confirmed; other sizes require manufacturer assessment. Reach is inspection distance.

    Which supplier is listed for the Hibot SQUID?

    Hibot SQUID is listed under Hibot, based in Japan. Check local sales and support terms directly with the supplier.

    Is the Hibot SQUID available to buy or lease in the Netherlands?

    Commercially available. Deployment: not confirmed. Whether this model is available to buy, rent or lease in the Netherlands depends on the supplier. Ask a supplier to confirm current availability.

    How much does the Hibot SQUID cost?

    No reliable public price is listed for this model. Costs depend on configuration and supplier. Ask a supplier for price information

    What is the Hibot SQUID used for?

    The applications listed for the Hibot SQUID include wall-thickness measurement in industrial boiler tubes and reporting ultrasonic tube inspections.

    What are alternatives to the Hibot SQUID?

    Profiles include Exail Iguana, Exail Cameleon LG and Autel Robotics Dragonfish Series. Compare their applications, specifications and market status.
